Ade Advanced Optics 1-6x24 riflescope uses cutting edge glass and lens coatings to ensure that it is the most accurate tactical instrument on the market. Multicoated lenses offer the clearest view for easy target acquisition in both bright and low light situations.
Waterproof, shockproof and fog proof,
Nitrogen filled.
Oversized windage, elevation and focusing adjustment knobs for easy adjustment in the field.
Locking mechanisms on the windage and elevation adjustments provide an additional level of accuracy and ensure that the scope stays zeroed.
• Precision accuracy adjustment lock
• Circle dot duplex reticle
• Wide field of view
• Precision multi-coated optics
•Iinternal lit reticle
• 1/2” locking moa
• Easy focusing knob
• Side diopter adjustment
• Lightweight
• Waterproof and Shockproof
• Includes a Set of 30 mm Mounting rings, Manual and Limited Lifetime Warranty
Specifications
|
Reticle type |
Circle Dot Duplex Reticle |
|
Reticle color |
black/red |
|
Illuminated (yes/no) |
yes |
|
Reticle brightness settings |
0-11 |
|
Finish/color |
Matte Black |
|
Magnification (x) |
1-6 |
|
Objective lens diameter (mm) |
24 |
|
Eyepiece diameter (mm) |
36.5MM |
|
Exit pupil diameter (mm) |
16.0-4.0 |
|
Eye relief (mm) |
110-88 |
|
Field of view (m @100m) |
33.47-5.53 |
|
Field of view (ft @100yd) |
100.4-16.6 |
|
Diopter adjustment (+/-) |
+2/-3 |
|
Diopter adjustment (dpt) |
+2/-3 |
|
Tube diameter (mm) |
30mm |
|
Max internal adjustment (MOA) |
90 |
|
Parallax setting (yds) |
100YDS |
|
Windage (MOA) |
90 |
|
Elevation (MOA) |
90 |
|
Windage & Elevation lock (yes/no) |
yes |
|
MOA adjustment (one click) |
1/2" |
|
Maximum recoil (G's) |
1000G |
|
Battery type |
CR2032 |
|
Battery life (hours) |
80-150 |
|
Battery voltage (V) |
3V |
|
Sunshade (yes/no) |
no |
|
Waterproof/nitrogen filled (yes/no) |
yes |
|
Shockproof (yes/no) |
yes |
|
Fog proof (yes/no) |
yes |
|
Focal plane |
2nd |
|
IP Standard (water rating) |
IPX4 |
|
Body material |
HI-GRADE ALUMINUM |
|
Lens material/type |
K、ZF、BaK |
|
Lens coatings |
Full bond AR coating |
|
Mount type |
weaver |
|
Operating temperature (°С) |
-20℃～60℃ |
|
Storage temperature (°С) |
5℃～35℃ |
|
Length (mm) |
390 |
|
Width (mm) |
116 |
|
Height (mm) |
85 |
|
Weight (oz) |
19.4 |
